Made of durable steel profiles, powder coated (resistance to mechanical damage, chemicals and UV radiation). The bed frame is supported at 4 points, and the casters at 6 points.
Bed platform:
Four-section, with three movable sections. Panels removable without tools (snap-in system), with ventilation openings and belt attachments. Panel material options (ABS, PP or HPL).
Overall dimensions:
214 x 100 cm.
Mattress platform dimensions:
195 x 85 cm.
Safe working load:
270 kg.
Propulsion system:
Antistatic dual wheels with non-marking tread (diameter 15 cm). Central lock with directional drive function and LED indicator (red/green). Optional 5th wheel.
Electrical adjustment range
Bed height:
39 – 82 cm.
Backrest:
0° – 70°.
Thigh support:
0° – 40°.
Trendelenburg / Anti-Trendelenburg:
0° – 17° / 0° – (-17°).
Lower leg section:
Mechanically adjustable with a 10-position raster-type detent.
Functions and safety
Safety system:
Autoconformation function and double mechanical autoregress (total 16 cm).
CPR system:
Electrical and mechanical (levers on both sides of the backrest).
Alarms:
Audible and visual alarm for brake not engaged (flashing LED) and minimum bed height indicator.
Bed extension:
Can be extended by 20 cm for tall patients.
Side rails:
Can be lowered with one hand, made of ABS, with tilt angle indicators (compliant with IEC 60601-2-52).
Control
Nurse panel:
Allows selective blocking of electrical functions. Equipped with clear pictograms and one-touch functions (shock position, cardiology chair, Fowler).
Integrated rails panels:
Internal (patient):
Height adjustment, backrest, thigh, autoconform and LED lighting.
External (staff):
Full control of functions, including Trendelenburg, with diode status indication.
Power and additional parameters
Power supply:
230 V, 50 Hz, IPX6 class. Equipped with emergency battery power.
Standard equipment:
IV stand, arm with holder, linen shelf, hooks for urinary bags, floor LED lighting.
Product status:
New.
Documentation:
Current Technical Passport.
Origin:
Turkish production,
Warranty and financing
Warranty:
24 months
Financing options (Poland):
Installments, Leasing, Loan.
