- Reconditioned (used),
- Technical condition: very good,
- Visual condition: very good,
- Real photos of the product,
- Made in Germany,
- Power supply: 230 V,
- Emergency power supply: via 2 new 12 V / 7 Ah batteries,
- Frequency: 50/60 Hz,
- Power: 280 W,
- Software: 6.43,
- Has one port for vaporizer with common Dräger DW-2000 connector systems, no vaporizer included - can be retrofitted at additional cost,
- Supplied with gases from the central plant: O2, N2O, AIR,
- Possibility to supply gases from additional O2 or N2O cylinders,
- Respirator driven by electric motor (electronically controlled),
- Built-in DRAGER gas measurement monitor with water trap:
- With inspiratory and expiratory measurement of oxygen, nitrous oxide, carbon dioxide and 5 anesthetic gases: DES, ENF, HAL, ISO, SEV,
- Audible and visual alarms,
- Foiled control panel,
- Ventilation modes:
- Manual ventilation (MAN),
- Spontaneous breathing (SPONT),
- Volume-limited ventilation (VC),
- Ventilator measurement functions:
- PMAX (V): 5 - 70 mbar,
- VT: 20 - 1400 mL,
- f: 6 - 80 bpm,
- Ti/Te: 1:3 to 2:1,
- Tip/Ti: 0% - 60%,
- PEEP: 0.2 - 20 mbar,
- Insp Flow: ≤ 75 L / min,
- Infinitely adjustable gas flow: O2, AIR, N2O, from 0.0 to 12 L / min, (digital displays and pressure gauges),
- Monitored are:
- Airway pressure,
- Expiratory minute volume AMV,
- Inspiratory O2 concentration,
- Inspiratory and expiratory CO2 concentration,
- Inspiratory anesthetic concentration,
- Displayed are:
- Continuous curve of airway pressure, peak pressure and plateau pressure, mean pressure and PEEP,
- Expiratory minute volume, tidal volume and respiratory rate,
- Expiratory flow rate curve,
- Inspiratory O2 concentration,
- Inspiratory and expiratory concentration of N2O and anesthetic agent,
- Inspiratory and end-expiratory CO2 concentration (inCO2 and etCO2),
- Continuous CO2 curve,
- INJECTOR DRAGGER SUCTION JAR:
- DRAGER suction jar with a capacity of 700 ml suitable for phlegm extraction,
- Compact heated patient system,
- Replaceable soda lime tank,
- Built-in LED monitor with gas measurement function: O2, AIR, N2O, and control panel and ventilator function display,
- Easy to use and easy to read display,
- Space for two gas cylinders,
- Selectable menu in the following languages: EN, NL, DE, FR, IT, ES,
- The device has been retrofitted with:
- SOLAR 800M modular patient monitoring system with monitor:
- This is a modular patient monitoring system that improves clinical decision-making with a constant flow of high-quality information. It provides robust clinical standards, including basic vital signs and advanced cardiac care,
- TRAM-RAC 2 module:
- ECG,
- TEMP/CO,
- 2x BP,
- BP/BP,
- NBP,
- DISPLAY
- Defib. Sync,
- SPO2,
- Wired modules:
- ECG - Brand new 3-lead ECG cable,
- SPO2 - Brand new sensor,
- NIBP - Cuff + air line,
- Included:
- Power cord,
- Gas supply hoses with customer-selectable ends (AGA or DIN),
- Patient breathing circuit,
- Sampling line for gas measurement,
- ECG - Brand new 3-lead ECG lead,
- SPO2 - Brand new sensor,
- NIBP - Cuff + air line,
- Dimensions: 96 x 73 x 200 cm
- Weight: 155 KG,
- Cat 02,
- In the domestic market (Poland) the price of the device includes delivery, equipment installation and training, in the case of installation of the device within 30 days from the date of delivery of the equipment (after this time these services will be charged),
- Has a current inspection and is ready for operation,
- Issued Technical Passport (Service Report) valid for a period of 12 months,
- Warranty:
- 6-months for domestic market (Poland),
- 3-months for the international market,
- Possibility to extend the warranty up to 12-months for domestic and international market for a surcharge,
- Financing options (Poland only): Installments, Leasing, Loan,
